TOSHIBA
8 - 7
GROUP:TERMINAL SELECTION PARAMETERS (cont'd)
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
FACTORY
SETTING
"FP" OUTPUT TERMINAL 78 Output terminal pulse 0: 48 times output frequency 0 9-13
PULSE FREQUENCY frequency selection 1: 96 times output frequency 5-1
2: 360 times output frequency
RR INPUT SPECIAL 79 RR input special function selection 0: Standard 0 9-13
FUNCTION SELECT 1: Set effective Maximum 5-1
Output Frequency
2: Scale ACC/DEC times
3: Set effective Voltage Boost
4: Set effective Stall Level
