Toshiba, Group:panel control parameters – Toshiba Adjustable Speed Drive H3 User Manual
Page 38

TOSHIBA
DIRECTION SELECTION
25
Forward/reverse
0: Reverse
-
1
9-5
(FORWARD/REV)
1: Forward
STOP PATTERN
26
Stop pattern selection
0: Decelerated stop
-
0
9-5
SELECTION
1: Coast stop
FUNDAMENTAL PARAM
27
Fundamental parameter #1 or #2
1: Fundamental
-
1
9-5
SWITCHING
selection
parameter #1
2: Fundamental
parameter #2
ACCEL/DECEL #1/#2
28
Acc/dec #1 or #2
1: Acc/dec #1
-
1
9-6
SELECTION
selection
2: Acc/dec #2
PANEL RESET
29
Panel reset selection
0: All possible
-
0
9-6
SELECTION
1: Only OL can be
reset
2: Only OL, OC1,
OC2, OC3 can be
reset
PANEL FEEDBACK
30
Panel feedback control
0: On (valid when
-
0
9-6
CONTROL
(PID, speed feedback, drooping)
panel operation is
selected)
1: Off (invalid when
panel operation is
selected)
8 - 3
GROUP:PANEL CONTROL PARAMETERS
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY
ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
