PASS NUMBER 284 Panel operation mode selection 0 - 99 - 0 9-26
CPU VERSION 285 CPU version Can be monitored only - 120 9-26
ROM VERSION 286 ROM version Can be monitored only - 6800 9-26
EEPROM VERSION 287 EEPROM version Can be monitored only - 100 9-26
INVERTER TYPEFORM 288 Inverter typeform Can be monitored only - - 9-26
STATUS MONITOR #1 289 Programmable monitor #1 1: post-compensation - 2 9-27
DISPLAY SELECT (displayed in MON mode) output frequency
2: frequency
command setting
3: output current
4: input voltage
5: output voltage
6: torque current
7: excitation current
8: PID feedback value
9: motor overload
ratio
10:inverter overload
ratio
11:DBR overload ratio
12:input power
13:output power
14:RR input value
15:peak load current
16:peak input voltage
STATUS MONITOR #2 290 Programmable monitor #2 Same options as - 3 9-27
DISPLAY SELECT (displayed in MON mode) Item 289
STATUS MONITOR #3 291 Programmable monitor #3 Same options as - 4 9-27
DISPLAY SELECT (displayed in MON mode) Item 289
STATUS MONITOR #4 292 Programmable monitor #4 Same options as 5 9-27
DISPLAY SELECT (displayed in MON mode) Item 289
FREQUENCY UNITS 293 multiplier to scale Hz display 0 (Off), 0.01 - 200 0.01 0.00 9-27
SCALE FACTOR
FREQUENCY DISPLAY 294 Frequency display resolution 0: 1 Hz - 1 9-27
RESOLUTION 1: 0.1 Hz
2: 0.01 Hz
ACC/DEC TIME UNITS 295 ACC/DEC time units selection 0: 0.1 secs - 0 9-27
SELECTION 1: 0.01 secs
CURRENT UNITS 296 Current units selection 0: % - 0 9-27
SELECTION 1: A
VOLTAGE UNITS 297 Voltage units selection 0: % - 1 9-27
SELECTION 1: V
8 - 30
GROUP:UTILITY PARAMETERS (cont'd)
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
Table continued on next page
