Toshiba, Group:pattern run control parameters – Toshiba Adjustable Speed Drive H3 User Manual
Page 51
TOSHIBA
PATTERN RUN
175
Pattern run on/off
0: Off
-
0
9-19
SELECTION
1: On *
PATTERN RUN CONTINUE
176*
Pattern run mode
0: Pattern is reset
-
0
9-19
MODE
when inverter
is stopped
1: Pattern resumes
with speed of
interruption and
with time left at
interruption
PATTERN GROUP #1
177*
1st Pattern Group
0: Skip
-
1
9-20
SPEED #0
1st speed selection
1: Preset speed #1
2: Preset speed #2
3: Preset speed #3
4: Preset speed #4
5: Preset speed #5
6: Preset speed #6
7: Preset speed #7
8: Preset speed #8
9: Preset speed #9
10:Preset speed #10
11:Preset speed #11
12:Preset speed #12
13:Preset speed #13
14:Preset speed #14
15:Preset speed #15
PATTERN GROUP #1
178*
1st Pattern Group
Same options as
-
2
9-20
SPEED #1
2nd speed selection
Item 177
PATTERN GROUP #1
179*
1st Pattern Group
Same options as
-
3
9-20
SPEED #2
3rd speed selection
Item 177
PATTERN GROUP #1
180*
1st Pattern Group
Same options as
-
4
9-20
SPEED #3
4th speed selection
Item 177
PATTERN GROUP #1
181*
1st Pattern Group
Same options as
-
5
9-20
SPEED #4
5th speed selection
Item 177
PATTERN GROUP #1
182*
1st Pattern Group
Same options as
-
6
9-20
SPEED #5
6th speed selection
Item 177
PATTERN GROUP #1
183*
1st Pattern Group
Same options as
-
7
9-20
SPEED #6
7th speed selection
Item 177
PATTERN GROUP #1
184*
1st Pattern Group
Same options as
-
8
9-20
SPEED #7
8th speed selection
Item 177
8 - 16
GROUP:PATTERN RUN CONTROL PARAMETERS
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY
ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
Table continued on next page
*Items 176 - 184 are available only when Item 175 Adjustment Range option 1 is selected.
