TOSHIBA
PRESET SPEED 110 Selects number of preset speeds 0: Disabled - 0 9-15
SELECTION to be unblinded 1: 1st speed only *
2: speeds 1 thru 2 *
3: speeds 1 thru 3*
4: speeds 1 thru 4*
5: speeds 1 thru 5*
6: speeds 1 thru 6*
7: speeds 1 thru 7*
8: speeds 1 thru 8*
9: speeds 1 thru 9*
10:speeds 1 thru 10*
11:speeds 1 thru 11*
12:speeds 1 thru 12*
13:speeds 1 thru 13*
14:speeds 1 thru 14*
15:speeds 1 thru 15*
PRESET SPEED MODE 111* Mode selection 0: Deactivated - 0 9-15
ACTIVATION 1: Activated
PRESET SPEED #1 112* 1st speed Lower limit frequency 0.1/0.01 Hz 0.0 9-15
FREQUENCY to
upper limit frequency
PRESET SPEED #1 113* 1st speed run mode 0: Acc/dec #1, 0 9-15
OPERATING MODE forward run
1: Acc/dec #1,
reverse run
2: Acc/dec #2,
forward run
3: Acc/dec #2,
reverse run
4: Acc/dec #1,
forward run
5: Acc/dec #1,
reverse run
6: Acc/dec #2,
forward run
7: Acc/dec #2,
reverse run
PRESET SPEED #2 114* 2nd speed Lower limit frequency 0.1/0.01 Hz 0.0 9-15
FREQUENCY to
upper limit frequency
PRESET SPEED #2 115* 2nd speed run mode Same options as - 0 9-15
OPERATING MODE Item 113
PRESET SPEED #3 116* 3rd speed Lower limit frequency 0.1/0.01 Hz 0.0 9-15
FREQUENCY to
upper limit frequency
PRESET SPEED #3 117* 3rd speed run mode Same options as - 0 9-15
OPERATING MODE Item 113
8 - 10
GROUP:FREQUENCY SETTING PARAMETERS (cont'd)
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
Table continued on next page
*Items 111 - 117 are available only when Item 110 Adjustment Range options 1 - 15 are selected.
