TOSHIBA
8 - 9
GROUP:FREQUENCY SETTING PARAMETERS (cont'd)
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
Table continued on next page
*Items 99 - 102 are available only when Item 98 Adjustment Range option 1 is selected.
**Items 104 - 107 are available only when Item 103 Adjustment Range option 1 is selected.
***Item 109 is available only when Item 108 Adjustment Range is set to other than "0".
PG TERMINAL STANDARD 98 Bias/gain for PG input selection 0: Standard - 0 9-14
OR ADJUSTABLE (option board) 1: Adjustable*
PG REFERENCE SETTING 99* PG reference point #1 -100 - 100% of Max. 1% 0 9-14
POINT #1 Out. Freq. X PPR
PG REF POINT #1 100* Output Hz desired when reference -Max. Out. Freq. to 0.1/0.01 Hz 0.0 9-14
FREQUENCY equals value entered in Item 99 Max. Out. Freq.
PG REFERENCE SETTING 101* PG reference point #2 -100 - 100% of Max. 1% 100 9-14
POINT #2 Out. Freq. X PPR
PG REF POINT #2 102* Output Hz desired when reference -Max. Out. Freq. to 0.1/0.01 Hz 80.0 9-14
FREQUENCY equals value entered in Item 101 Max. Out. Freq.
BINARY INPUT STD 103 Bias/gain for binary input 0: Standard - 0 9-14
OR ADJUSTABLE (via input terminals). 1: Adjustible**
BINARY REF SETTING 104** Binary reference point #1 0 - 100 % 1% 0 9-14
POINT #1
BINARY REF POINT #1 105** Output Hz desired when reference -Max. Out. Freq. to 0.1/0.01 Hz 0.0 9-14
FREQUENCY equals value entered in Item 104 Max. Out. Freq.
BINARY REF SETTING 106** Binary reference point #2 0 - 100 % 1% 100 9-14
POINT #2
BINARY REF POINT #2 107** Output Hz desired when reference -Max. Out. Freq. to 0.1/0.01 Hz 80.0 9-14
FREQUENCY equals value entered in Item 106 Max. Out. Freq.
JOG RUN FREQUENCY 108 Jog run frequency 0.0 - 20*** 0.1/0.01 Hz 0.0 9-15
JOG STOP METHOD 109*** Jog stop control 0: Decelerated stop - 0 9-15
1: Coast to stop
2: DC injection
braking
