TOSHIBA
8 - 23
GROUP:FEEDBACK PARAMETERS (cont'd)
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
OVERRIDE CONTROL 257 trim source 0: Off - 0 9-22
SELECTION 1: "RR" terminal
2: "IV" terminal
3: "RX" terminal
4: PG option board
5: Keypad
6: All other opt board
7: Multiplier
OVERRIDE MULTIPLIER 258* trim source selection 0: Reference - 0 9-22
INPUT SELECTION 1: "RR" terminal.
2: "IV" terminal
3: "RX" terminal
4: Binary input
OVERRIDE CHANGE 259* sets trim range -100.0 - 100.0% 0.1% 0.0 9-22
MULTIPLIER of reference
*Items 258 - 259 are available only when Item 257 Adjustment Range option 7 is selected.
