7.3.4 AGP Clock Routing
The maximum total AGP clock skew, between the GMCH and the graphics component, is 1 ns for
all data transfer modes. This 1 ns includes skew and jitter that originates on the motherboard, add-
in card, and clock synthesizer. Clock skew must be evaluated not only at a single threshold
voltage, but at all points on the clock edge that fall within the switching range. The 1 ns skew
budget is divided such that the motherboard is allotted 0.9 ns of clock skew. (The motherboard
designer shall determine how the 0.9 ns is allocated between the board and the synthesizer.)
7.3.5 AGP Signal Noise Decoupling Guidelines
The following routing guidelines are recommended for an optimal system design. The main focus
of these guidelines is to minimize signal integrity problems on the AGP interface of the GMCH.
The following guidelines are not intended to replace thorough system validation for products
based on the Intel 815 chipset platform.
•
A minimum of six 0.01
µ
F capacitors are required and must be as close as possible to the
GMCH. These should be placed within 70 mils of the outer row of balls on the GMCH for
VDDQ decoupling. The closer the placement, the better.
•
The designer should evenly distribute placement of decoupling capacitors in the AGP
interface signal field.
•
It is recommended that the designer use a low-ESL ceramic capacitor (e.g., with a 0603 body-
type X7R dielectric).
•
To add the decoupling capacitors within 70 mils of the GMCH and/or close to the vias, the
trace spacing may be reduced as the traces go around each capacitor. The narrowing of space
between traces should be minimal and for as short a distance as possible (1 inch maximum).
•
In addition to the minimum decoupling capacitors, the designer should place bypass
capacitors at vias that transition the AGP signal from one reference signal plane to another.
On a typical four layer PCB design, the signals transition from one side of the board to the
other. One extra 0.01
µ
F capacitor is required per 10 vias. The capacitor should be placed as
close as possible to the center of the via field.
The designer should ensure that the AGP connector is well decoupled, as described in the AGP
Design Guide, Revision 1.0, Section 1.5.3.3.
