System Design Checklist
R
Intel
®
815 Chipset Platform Design Guide 155
13 System Design Checklist
13.1 Design Review Checklist
Introduction
This checklist highlights design considerations that should be reviewed prior to manufacturing a
motherboard that implements an Intel 815 chipset platform for use with the universal socket 370.
This is not a complete list and does not guarantee that a design will function properly. For items
other than those in the following text, refer to the latest revision of the design guide for more-
detailed instructions regarding motherboard design.
Design Checklist Summary
The following set of tables provides design considerations for the various portions of a design.
Each table describes one of those portions and is titled accordingly. Contact your Intel Field
Representative in the event of questions or issues regarding the interpretation of the information in
these tables.
13.2 Processor Checklist
13.2.1 GTL Checklist
Checklist Items Recommendations
A[35:3]# • Connect A[31:3]# to GMCH. Leave A[35:32]# as No Connect (not
supported by chipset).
BNR#, BPRI#, DBSY#,
DEFER#, DRDY#, D[63:0]#,
HIT#, HITM#, LOCK#,
REQ[4:0]#, RS[2:0]#,
TRDY# • Connect to GMCH.
ADS# • Resistor site for 56 Ω pull-up to VTT placed within 150 mils of GMCH for
debug purpose. Connect to GMCH.
BREQ[0]# (BR0#) • 33 Ω pull-down resistor to ground
RESET# (AH4) • Terminate to VTT through 86 Ω resistor, decoupled through 22 Ω resistor
in series with 10 pF capacitor to ground. Connect to GMCH. For ITP,
also connect to ITP pin 2 (RESET#) with 240
Ω series resistor.
RESET2# (X4) • 1 k Ω series resistor to RESET#.
