Register Name:
IMR4
Register Description:
Interrupt Mask Register 4
Register Address:
1Dh
Bit #
7
6
5
4
3
2
1
0
Name
-
RSA1
RSA0
TMF
TAF
RMF
RCMF
RAF
Default
0
0
0
0
0
0
0
0
Bit 0/Receive Align Frame Event (RAF).
0 = interrupt masked
1 = interrupt enabled
Bit 1/Receive CRC4 Multiframe Event (RCMF).
0 = interrupt masked
1 = interrupt enabled
Bit 2/Receive Multiframe Event (RMF).
0 = interrupt masked
1 = interrupt enabled
Bit 3/Transmit Align Frame Event (TAF).
0 = interrupt masked
1 = interrupt enabled
Bit 4/Transmit Multiframe Event (TMF).
0 = interrupt masked
1 = interrupt enabled
Bit 5/Receive Signaling All Zeros Event (RSA0).
0 = interrupt masked
1 = interrupt enabled
Bit 6/Receive Signaling All Ones Event (RSA1).
0 = interrupt masked
1 = interrupt enabled
