Register Name:
TSa4
Register Description:
Transmit Sa4 Bits
Register Address:
D5h
Bit #
7
6
5
4
3
2
1
0
Name
TSa4F1
TSa4F3
TSa4F5
TSa4F7
TSa4F9
TSa4F11
TSa4F13
TSa4F15
Default
0
0
0
0
0
0
0
0
Bit 0/Sa4 Bit of Frame 15(TSa4F15).
Bit 1/Sa4 Bit of Frame 13(TSa4F13).
Bit 2/Sa4 Bit of Frame 11(TSa4F11).
Bit 3/Sa4 Bit of Frame 9(TSa4F9).
Bit 4/Sa4 Bit of Frame 7(TSa4F7).
Bit 5/Sa4 Bit of Frame 5(TSa4F5).
Bit 6/Sa4 Bit of Frame 3(TSa4F3).
Bit 7/Sa4 Bit of Frame 1(TSa4F1).
Register Name:
TSa5
Register Description:
Transmit Sa5 Bits
Register Address:
D6h
Bit #
7
6
5
4
3
2
1
0
Name
TSa5F1
TSa5F3
TSa5F5
TSa5F7
TSa5F9
TSa5F11
TSa5F13
TSa5F15
Default
0
0
0
0
0
0
0
0
Bit 0/Sa5 Bit of Frame 15(TSa5F15).
Bit 1/Sa5 Bit of Frame 13(TSa5F13).
Bit 2/Sa5 Bit of Frame 11(TSa5F11).
Bit 3/Sa5 Bit of Frame 9(TSa5F9).
Bit 4/Sa5 Bit of Frame 7(TSa5F7).
Bit 5/Sa5 Bit of Frame 5(TSa5F5).
Bit 6/Sa5 Bit of Frame 3(TSa5F3).
Bit 7/Sa5 Bit of Frame 1(TSa5F1).
