Register Name:
TSa8
Register Description: Transmit Sa8 Bits
Register Address: D9h
Bit #
7 6 5 4 3 2 1 0
Name TSa8F1 TSa8F3 TSa8F5 TSa8F7 TSa8F9 TSa8F11 TSa8F13 TSa8F15
Default 0 0 0 0 0 0 0 0
Bit 0/Sa8 Bit of Frame 15(TSa8F15).
Bit 1/Sa8 Bit of Frame 13(TSa8F13).
Bit 2/Sa8 Bit of Frame 11(TSa8F11).
Bit 3/Sa8 Bit of Frame 9(TSa8F9).
Bit 4/Sa8 Bit of Frame 7(TSa8F7).
Bit 5/Sa8 Bit of Frame 5(TSa8F5).
Bit 6/Sa8 Bit of Frame 3(TSa8F3).
Bit 7/Sa8 Bit of Frame 1(TSa8F1).
