MOTOROLA BUS READ TIMING (BTS = 1 / MUX = 0) Figure 37-6
MOTOROLA BUS WRITE TIMING (BTS = 1 / MUX = 0) Figure 37-7
Address Valid
Data Valid
A0 to A7
D0 to D7
R/W*
CS*
DS*
0ns min.
0ns min.
75ns max.
0ns min.
5ns min. / 20ns max.
t1
t2
t3
t4
t5
Address Valid
A0 to A7
D0 to D7
R/W*
CS*
DS*
0ns min.
0ns min.
75ns min.
0ns min.
10ns
min.
10ns
min.
t1
t2
t6
t4
t7 t8
