Product Preview DS21Q55
33 of 248 012103
Please contact [email protected] or search http://www.maxim-ic.com for updated
information.
ADDRESS R/W REGISTER NAME
REGISTER
ABBREVIATION
PAGE
8E Transmit Channel Blocking Register 3 TCBR3 *
8F Transmit Channel Blocking Register 4 TCBR4 *
90 HDLC #1 Transmit Control H1TC *
91 HDLC #1 FIFO Control H1FC *
92 HDLC #1 Receive Channel Select 1 H1RCS1 *
93 HDLC #1 Receive Channel Select 2 H1RCS2 *
94 HDLC #1 Receive Channel Select 3 H1RCS3 *
95 HDLC #1 Receive Channel Select 4 H1RCS4 *
96 HDLC #1 Receive Time Slot Bits/Sa Bits Select H1RTSBS *
97 HDLC #1 Transmit Channel Select1 H1TCS1 *
98 HDLC #1 Transmit Channel Select 2 H1TCS2 *
99 HDLC #1 Transmit Channel Select 3 H1TCS3 *
9A HDLC #1 Transmit Channel Select 4 H1TCS4 *
9B HDLC #1 Transmit Time Slot Bits/Sa Bits Select H1TTSBS *
9C HDLC #1 Receive Packet Bytes Available H1RPBA *
9D HDLC #1 Transmit FIFO H1TF *
9E HDLC #1 Receive FIFO H1RF *
9F HDLC #1 Transmit FIFO Buffer Available H1TFBA *
A0 HDLC #2 Transmit Control H2TC *
A1 HDLC #2 FIFO Control H2FC *
A2 HDLC #2 Receive Channel Select 1 H2RCS1 *
A3 HDLC #2 Receive Channel Select 2 H2RCS2 *
A4 HDLC #2 Receive Channel Select 3 H2RCS3 *
A5 HDLC #2 Receive Channel Select 4 H2RCS4 *
A6 HDLC #2 Receive Time Slot Bits/Sa Bits Select H2RTSBS *
A7 HDLC #2 Transmit Channel Select 1 H2TCS1 *
A8 HDLC #2 Transmit Channel Select 2 H2TCS2 *
A9 HDLC #2 Transmit Channel Select 3 H2TCS3 *
AA HDLC #2 Transmit Channel Select 4 H2TCS4 *
AB HDLC #2 Transmit Time Slot Bits/Sa Bits Select H2TTSBS *
AC HDLC #2 Receive Packet Bytes Available H2RPBA *
AD HDLC #2 Transmit FIFO H2TF *
AE HDLC #2 Receive FIFO H2RF *
AF HDLC #2 Transmit FIFO Buffer Available H2TFBA *
B0 Extend System Information Bus Control Register 1 ESIBCR1 *
B1 Extend System Information Bus Control Register 2 ESIBCR2 *
B2 Extend System Information Bus Register 1 ESIB1 *
B3 Extend System Information Bus Register 2 ESIB2 *
B4 Extend System Information Bus Register 3 ESIB3 *
B5 Extend System Information Bus Register 4 ESIB4 *
B6 In-Band Code Control Register IBCC *
B7 Transmit Code Definition Register 1 TCD1 *
B8 Transmit Code Definition Register 2 TCD2 *
B9 Receive Up Code Definition Register 1 RUPCD1 *
BA Receive Up Code Definition Register 2 RUPCD2 *
BB Receive Down Code Definition Register 1 RDNCD1 *
BC Receive Down Code Definition Register 2 RDNCD2 *
BD In-Band Receive Spare Control Register RSCC *
BE Receive Spare Code Definition Register 1 RSCD1 *
BF Receive Spare Code Definition Register 2 RSCD2 *
C0 Receive FDL Register RFDL *
C1 Transmit FDL Register TFDL *
