RECEIVE SIDE BOUNDARY TIMING (With Elastic Store Disabled)
Figure 35-12
NOTES:
1) RCHBLK is programmed to block channel 1.
2) RLCLK is programmed to mark the Sa4 bit in RLINK.
3) Shown is a RNAF frame boundary.
4) RSIG normally contains the CAS multiframe-alignment nibble (0000) in channel 1.
CHANNEL 32
CHANNEL 1
CHANNEL 2
CHANNEL 32
CHANNEL 1
CHANNEL 2
RCLK
RSER
RSYNC
RFSYNC
RSIG
RCHCLK
RCHBLK
1
RLCLK
RLINK
2
C
D
A
LSB
MSB
A
B
Si
1
A
Sa4 Sa5 Sa6 Sa7 Sa8
Sa4 Sa5 Sa6 Sa7 Sa8
B
Note 4
