Register Name:
IBCC
Register Description:
In-Band Code Control Register
Register Address:
B6h
Bit #
7
6
5
4
3
2
1
0
Name
TC1
TC0
RUP2
RUP1
RUP0
RDN2
RDN1
RDN0
Default
0
0
0
0
0
0
0
0
Bits 0 to 2/Receive -Down Code Length Definition Bits (RDN0 to RDN2).
RDN2
RDN1
RDN0
LENGTH SELECTED (Bits)
0
0
0
1
0
0
1
2
0
1
0
3
0
1
1
4
1
0
0
5
1
0
1
6
1
1
0
7
1
1
1
8/16
Bits 3 to 5/Receive -Up Code Length Definition Bits (RUP0 to RUP2).
RUP2
RUP1
RUP0
LENGTH SELECTED (Bits)
0
0
0
1
0
0
1
2
0
1
0
3
0
1
1
4
1
0
0
5
1
0
1
6
1
1
0
7
1
1
1
8/16
Bits 6 to 7/Transmit Code Length Definition Bits (TC0 to TC1).
TC1
TC0
LENGTH SELECTED (Bits)
0
0
5
0
1
6/3
1
0
7
1
1
16/8/4/2/1
