Register Name:
TSiAF
Register Description:
Transmit Si Bits of the Align Frame
Register Address:
D2h
Bit #
7
6
5
4
3
2
1
0
Name
TsiF0
TsiF2
TsiF4
TsiF6
TsiF8
TsiF10
TsiF12
TsiF14
Default
0
0
0
0
0
0
0
0
Bit 0/Si Bit of Frame 14(TsiF14).
Bit 1/Si Bit of Frame 12(TsiF12).
Bit 2/Si Bit of Frame 10(TsiF10).
Bit 3/Si Bit of Frame 8(TsiF8).
Bit 4/Si Bit of Frame 6(TsiF6).
Bit 5/Si Bit of Frame 4(TsiF4).
Bit 6/Si Bit of Frame 2(TsiF2).
Bit 7/Si Bit of Frame 0(TsiF0).
