Register Name:
TSa6
Register Description:
Transmit Sa6 Bits
Register Address:
D7h
Bit #
7
6
5
4
3
2
1
0
Name
TSa6F1
TSa6F3
TSa6F5
TSa6F7
TSa6F9
TSa6F11
TSa6F13
TSa6F15
Default
0
0
0
0
0
0
0
0
Bit 0/Sa6 Bit of Frame 15(TSa6F15).
Bit 1/Sa6 Bit of Frame 13(TSa6F13).
Bit 2/Sa6 Bit of Frame 11(TSa6F11).
Bit 3/Sa6 Bit of Frame 9(TSa6F9).
Bit 4/Sa6 Bit of Frame 7(TSa6F7).
Bit 5/Sa6 Bit of Frame 5(TSa6F5).
Bit 6/Sa6 Bit of Frame 3(TSa6F3).
Bit 7/Sa6 Bit of Frame 1(TSa6F1).
Register Name:
TSa7
Register Description:
Transmit Sa7 Bits
Register Address:
D8h
Bit #
7
6
5
4
3
2
1
0
Name
TSa7F1
TSa7F3
TSa7F5
TSa7F7
TSa7F9
TSa7F11
TSa7F13
TSa7F15
Default
0
0
0
0
0
0
0
0
Bit 0/Sa7 Bit of Frame 15(TSa7F15).
Bit 1/Sa7 Bit of Frame 13(TSa7F13).
Bit 2/Sa7 Bit of Frame 11(TSa7F11).
Bit 3/Sa7 Bit of Frame 9(TSa7F9).
Bit 4/Sa7 Bit of Frame 7(TSa7F7).
Bit 5/Sa7 Bit of Frame 5(TSa7F5).
Bit 6/Sa7 Bit of Frame 3(TSa7F3).
Bit 7/Sa7 Bit of Frame 1(TSa4F1).
