Register Name:
IMR3
Register Description:
Interrupt Mask Register 3
Register Address:
1Bh
Bit #
7
6
5
4
3
2
1
0
Name
LSPARE
LDN
LUP
LOTC
LORC
V52LNK
RDMA
RRA
Default
0
0
0
0
0
0
0
0
Bit 0/Receive Remote Alarm Condition (RRA).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 1/Receive Distant MF Alarm Condition (RDMA).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 2/V5.2 Link Detected Condition (V52LNK).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 3/Loss of Receive Clock Condition (LORC).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 4/Loss of Transmit Clock Condition (LOTC).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 5/Loop Up Code Detected Condition (LUP).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 6/Loop Down Code Detected Condition (LDN).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 7/Spare Code Detected Condition (LSPARE).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
