Signal Name:
BPCLKx
Signal Description:
Back Plane Clock
Signal Type:
Output
A user-selectable synthesized clock output that is referenced to the clock that is output at the RCLK pin.
Signal Name:
RPOSOx
Signal Description:
Receive Positive Data Output
Signal Type:
Output
Updated on the rising edge of RCLKO with bipolar data out of the line interface. This pin is normally tied to RPOSI.
Signal Name:
RNEGOx
Signal Description:
Receive Negative Data Output
Signal Type:
Output
Updated on the rising edge of RCLKO with the bipolar data out of the line interface. This pin is normally tied to RNEGI.
Signal Name:
RCLKOx
Signal Description:
Receive Clock Output
Signal Type:
Output
Buffered recovered clock from the network. This pin is normally tied to RCLKI.
Signal Name:
RPOSIx
Signal Description:
Receive Positive Data Input
Signal Type:
Input
Sampled on the falling edge of RCLKI for data to be clocked through the receive-side framer. RPOSI and RNEGI can be tied
together for a NRZ interface. Can be internally connected to RPOSO by tying the LIUC pin high.
Signal Name:
RNEGIx
Signal Description:
Receive Negative Data Input
Signal Type:
Input
Sampled on the falling edge of RCLKI for data to be clocked through the receive-side framer. RPOSI and RNEGI can be tied
together for a NRZ interface. Can be internally connected to RNEGO by tying the LIUC pin high.
Signal Name:
RCLKIx
Signal Description:
Receive Clock Input
Signal Type:
Input
Clock used to clock data through the receive-side framer. This pin is normally tied to RCLKO. Can be internally connected to
RCLKO by tying the LIUC pin high.
3.3 Parallel Control Port Pins
Signal Name:
INT*
Signal Description:
Interrupt
Signal Type:
Output
Flags host controller during events, alarms, and conditions defined in the status registers. Active-low open-drain output.
Signal Name:
TSTRST
Signal Description:
3-State Control and Device Reset
Signal Type:
Input
A dual-function pin. A zero-to-one transition issues a hardware reset to the DS21Q55 register set. A reset clears all
configuration registers. Configuration register contents are set to zero. Leaving TSTRST high will 3-state all output and I/O
pins (including the parallel control port). Set low for normal operation. Useful in-board level testing.
