Register Name:
IMR9
Register Description:
Interrupt Mask Register 9
Register Address:
27h
Bit #
7
6
5
4
3
2
1
0
Name
-
BBED
BBCO
BEC0
BRA1
BRA0
BRLOS
BSYNC
Default
0
0
0
0
0
0
0
0
Bit 0/BERT in Synchronization Condition (BSYNC).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 1/Receive Loss Of Synchronization Condition (BRLOS).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 2/Receive All Zeros Condition (BRA0).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 3/Receive All Ones Condition (BRA1).
0 = interrupt masked
1 = interrupt enabled–interrupts on rising and falling edges
Bit 4/BERT Error Counter Overflow Event (BECO).
0 = interrupt masked
1 = interrupt enabled
Bit 5/BERT Bit Counter Overflow Event (BBCO).
0 = interrupt masked
1 = interrupt enabled
Bit 6/Bit Error Detected Event (BBED).
0 = interrupt masked
1 = interrupt enabled
BERT Alternating Word Count Rate. When the BERT is programmed in the alternating word mode, the words will repeat
for the count loaded into this register then flip to the other word and again repeat for the number of times loaded into this
register
Register Name:
BAWC
Register Description:
BERT Alternating Word Count Rate
Register Address:
DBh
Bit #
7
6
5
4
3
2
1
0
Name
ACNT7
ACNT6
ACNT5
ACNT4
ACNT3
ACNT2
ACNT1
ACNT0
Default
0
0
0
0
0
0
0
0
Bits 0 to 7/Alternating Word Count Rate Bits 0 to 7 (ACNT0 to ACNT7). ACNT0 is the LSB of the 8 -bit alternating word
count rate counter.
