26.1.1 Number Of Errors Left Register
The host can read the NOELx registers at any time to determine how many errors are left to be inserted.
Register Name:
NOEL1
Register Description:
Number Of Errors Left 1
Register Address:
EEh
Bit #
7
6
5
4
3
2
1
0
Name
C7
C6
C5
C4
C3
C2
C1
C0
Default
0
0
0
0
0
0
0
0
Bits 0 to 7/Number of Errors Left Counter Bits 0 to 7 (C0 to C7). Bit C0 is the LSB of the 10-bit counter.
Register Name:
NOEL2
Register Description:
Number Of Errors Left 2
Register Address:
EFh
Bit #
7
6
5
4
3
2
1
0
Name
-
-
-
-
-
-
C9
C8
Default
0
0
0
0
0
0
0
0
Bits 0 to 1/Number of Errors Left Counter Bits 8 to 9 (C8 to C9). Bit C9 is the MSB of the 10-bit counter.
