Product Preview
DS21Q55
125 of 248
012103
Please contact
or search
http://www.maxim-ic.com
for updated
information.
Register Name:
RSa8
Register Description:
Receive Sa8 Bits
Register Address:
CFh
Bit #
7
6
5
4
3
2
1
0
Name
RSa8F1
RSa8F3
RSa8F5
RSa8F7
RSa8F9
RSa8F11
RSa8F13
RSa8F15
Default
0
0
0
0
0
0
0
0
Bit 0/Sa8 Bit of Frame 15(RSa8F15).
Bit 1/Sa8 Bit of Frame 13(RSa8F13).
Bit 2/Sa8 Bit of Frame 11(RSa8F11).
Bit 3/Sa8 Bit of Frame 9(RSa8F9).
Bit 4/Sa8 Bit of Frame 7(RSa8F7).
Bit 5/Sa8 Bit of Frame 5(RSa8F5).
Bit 6/Sa8 Bit of Frame 3(RSa8F3).
Bit 7/Sa8 Bit of Frame 1(RSa8F1).
