HYDRAULIC CIRCUITS
Steering Circuit
Starting Serial No. 0255001
Original Issue 10-96
9-10 KG
Item Part No. Qty. Description Of Part
1 8471-8672 1 HOSE ASSY
2 8866-2105 1 ELBOW, 90 DEGREES (swivel nut)
3 8859-1205 5 O-RING
4 8866-2006 2 CONNECTOR (includes item 3)
5 8866-2018 1 CONNECTOR (includes item 3)
6 8866-2065 1 ELBOW, 90 DEGREES (includes
item 3)
7 8471-8432 1 HOSE ASSY
8 8471-8671 1 HOSE ASSY
9 8471-8676 1 HOSE ASSY
10 Ref STEERING COLUMN (see page 7-5
for details)
11 Ref STEERING CONTROL UNIT (see
page 7-5 for details)
12 8859-1202 1 O-RING
13 8866-2062 1 ELBOW, 90 DEGREES (includes
item 12)
14 8471-8673 1 HOSE ASSY
15 Ref FLOW DIVIDER ASSY (see page
10-9, item 18 for details)
16 Ref MAIN CONTROL VALVE (see page
10-14 for details)
17 8859-1210 1 O-RING
18 8866-2028 1 CONNECTOR (includes item 17)
19 9114-3058 1 TUBE ASSY
20 8471-8625 1 HOSE ASSY
21 Ref STEERING CYLINDER (see page
10-6 for details)
22 8859-1204 2 O-RING
23 8866-2064 2 ELBOW, 90 DEGREES (includes
item 22)
24 8471-8202 2 HOSE ASSY
25 9002-7187 12 TIE WRAP
26 8866-2140 2 RUN TEE (includes item 3)
27 8866-2106 2 ELBOW, 90 DEGREES (swivel nut)
28 7713-3390 1 SAFETY CLIP
29 8820-1023 1 HEX HD CAPSCREW, 5/16-18X1-3/4,
GR5
30 7732-3029 1 CLAMP SET
31 8366-3119 1 CLAMP SET
32 7713-3306 1 STACK BOLT
33 7713-3137 1 COVER PLATE
