Gradall 544C-10 - Manual (Page 169)

13-23 SVC
OPTIONAL EQUIPMENT
(9114-5098) Work Light Package
Starting Serial No. 0255016
Original Issue 10-00
40
42
43
39
41
19
36
44
45
45
86 30
87
RELAY
85
TO STOP LIGHT SWITCH
TO DOME LIGHT
IGN
A C C
ACC BAT
B AT
IGN
ST
CAB WALL
SEE VIEW C-C
GND
OIL
+12V
GND
LT
TEMP FUEL
ACC-C
AUXLT
TO
L.H.FR
T
CAB LIGHT
TO
R.H.FR
T CAB LIGHT
TO
REAR
TA
IL LIGHT
DASH SHOWN FLAT
FOR CLARITY
GND-5
BACK-UP
ALARM
REV
-B
FWD/REV VALVE
REV
FROM REV SWITCH
RELAY
30 86
85 87A 87
ACC-A
B
I
A
S
ACC-C/ACC-B
ACC-C
AUXL
T
WORK
LIGHT
SWITCH
15 AMP
FUSE
15 AMP
FUSE
IGNITION-START
SWITCH 15 AMP
FUSE
STOP
LIGHT
SWITCH
DOME
LIGHT
SWITCH
DOME
LIGHT
FRONT
WORK
LIGHT
FRONT
WORK
LIGHT
GND
REAR
TAIL LIGHT
ASSEMBLY
STOP
LIGHT
(RED)
TAIL
LIGHT
(BLACK)
BACK-UP
LIGHT
(GREEN)
ELECTRICAL SCHEMATIC
VOLTMETER
GAUGE
LIGHT
GAUGE
LIGHT
OIL PRESS.
GAUGE
FUEL
GAUGE
WATER TEMP.
GAUGE
LIGHTS
OFF
ON
0 0 0 0 0 0
QUARTZ DRIVE 4X4
4X2
ON
OFF ALT
PARK BRAKE
240
100
F
E
80
0
16
10
TEMP
FUEL OIL
VOLTS
- +
15 15 15 15 15 15
Item Part No. Qty. Description Of Part
9114-5098 1 WORK LIGHT PACKAGE, (includes all
items)
1 8096-3050 2 UTILITY FLOOD LIGHT
2 9114-1182 1 R.H. LIGHT SUPPORT
3 9114-1183 1 L.H. LIGHT SUPPORT
4 8096-3055 4 W. PACK CONNECTOR, (tower)
5 8820-1035 2 HEX HD CAPSCREW, 3/8-16X1, GR5
6 8856-1109 2 FLAT WASHER, 3/8
7 8855-1011 2 LOCKWASHER, 3/8
8 8850-1006 2 HEX NUT, 3/8-16
9 9002-7319 4 DR & TAP SCREW, 1/4-20X1
10 8688-3260 2 EYELET
11 8096-3056 3 W. PACK CONNECTOR, (shroud)
12 8096-3068 3 W. PACK CONNECTOR, (female pin)
13 9002-7214 8 RUBBER GROMMET
14 9101-1009 1 MOUNTING BRACKET
15 9002-9955 1 RUBBER GROMMET
16 8832-1022 2 SELF TAPPING SCREW, #8-32X3/8
17 2486-1167 1 INTERIOR LIGHT
18 8096-3069 9 W. PACK CONNECTOR, (male pin)
19 9114-3270 1 LIGHT HARNESS
20 8668-3122 6 TIE WRAP
21 9105-3419 19 TIE WRAP
22 8096-3066 12 W. PACK CONNECTOR, (cable seal)
23 9114-1197 1 MOUNTING TAB
24 9114-3117 1 STOPLIGHT SWITCH
25 9112-1145 1 TAIL LIGHT HOUSING
26 9112-1146 1 TAIL LIGHT BRACKET
Item Part No. Qty. Description Of Part
27 9136-5045 1 TAIL LIGHT ASSEMBLY, (includes the
following seven items)
9112-3065 1 TAIL LIGHT
8666-1147 38" WIRE, 16 GAUGE, (black)
8666-1149 38" WIRE, 16 GAUGE, (green)
8666-1152 38" WIRE, 16 GAUGE, (red)
8668-3480 3 BUTT CONNECTOR
8203-3996 45" WIRE LOOM
8668-3122 2 TIE WRAP
28 8820-1108 1 HEX HD CAPSCREW, 3/4-10X1-1/4,
GR5
29 8856-1115 1 FLAT WASHER, 3/4
30 8855-1016 1 LOCKWASHER, 3/4
31 8096-3058 1 W. PACK CONNECTOR, (shroud)
32 9114-1364 1 JUMPER WIRE
33 7738-3410 1 RELAY
34 8832-1039 1 SELF TAPPING SCREW, #10-32X1/2
35 9114-3210 1 TAIL LIGHT HARNESS
36 9114-1265 2 JUMPER WIRE
37 8096-3062 1 W. PACK CONNECTOR, (shroud)
38 AR WIRE LOOM, (use on all wires)
39 7736-3268 2 FUSE, 15 AMP
40 7738-3467 1 LIGHT SWITCH
41 9114-3108 2 FUSE HOLDER
42 7738-3470 1 BOOT
43 9136-3009 1 LIGHTS ON/OFF DECAL
44 9114-1266 1 JUMPER WIRE
45 9114-1259 2 JUMPER WIRE
