Gradall 544C-10 - Manual (Page 135)

12-2 KG
Item Part No. Qty. Description Of Part
9116-5037 1 544C-10 DECAL KIT (std. white)
(includes items 4 thru 6, 9 thru 26 & 29
thru 33 on page 12-1, plus items 5, 6 &
10 thru 22 on page 12-2)
1 9020-0445 1 PENDULUM
2 9020-0688 1 BEARING
3 9002-6491 1 SHOULDER BOLT, 1/4-20
4 8856-1108 1 WASHER, 5/16
5 9100-3031 1 BOOM ANGLE DECAL
6 7702-3009 7 HOLE WARNING DECAL
7 8820-1017 4 HEX HD CAPSCREW, 5/16-18X5/8,
GR5
8 9116-1206 1 BOOM END COVER
9 8855-1010 4 LOCKWASHER, 5/16
10 9112-3037 2 GRADALL DECAL (std.)
9112-3038 2 GRADALL DECAL (opt.)
11 9116-3050 2 544C-10 DECAL (std.)
9116-3051 2 544C-10 DECAL (opt.)
12 9103-3023 1 QUICK SWITCH DECAL
13 9116-3085 1 "10" DECAL (std.)
9116-3086 1 "10" DECAL (opt.)
14 9116-3083 1 "9" DECAL (std.)
9116-3084 1 "9" DECAL (opt.)
15 9116-3081 1 "8" DECAL (std.)
9116-3082 1 "8" DECAL (opt.)
16 9116-3079 1 "7" DECAL (std.)
9116-3080 1 "7" DECAL (opt.)
17 9116-3077 1 "6" DECAL (std.)
9116-3078 1 "6" DECAL (opt.)
18 9112-3044 1 "5" DECAL (std.)
9112-3045 1 "5" DECAL (opt.)
19 9100-3020 1 "4" DECAL (std.)
9104-3136 1 "4" DECAL (opt.)
20 9112-3042 1 "3" DECAL (std.)
9112-3043 1 "3" DECAL (opt.)
21 9100-3018 1 "2" DECAL (std.)
9104-3135 1 "2" DECAL (opt.)
22 9100-3016 1 "1" DECAL (std.)
9104-3134 1 "1" DECAL (opt.)
NOTE: STANDARD DECALS ARE
WHITE. OPTIONAL DECALS ARE
BLACK. ONLY STANDARD DECALS
ARE INCLUDED IN 9116-5037 DECAL
KIT.
MISCELLANEOUS
Boom Decals
Starting Serial No. 0255001
Original Issue 8-96
Revised 2-5-97
* Added dimensions to decals.
