CONTROLS
(9116-5103) Floorplate Assy
Starting Serial No. 0255001
Original Issue 7-96
Revised 1-18-02
SVC 7-4
Item Part No. Qty. Description Of Part
28 8471-8691 1 HOSE ASSY
29 9114-3200 1 RELIEF VALVE
30 8820-1008 4 HEX HD CAPSCREW, 1/4-20X1-3/4,
GR5
31 8856-1107 4 FLAT WASHER, 1/4
32 8855-1009 4 LOCKWASHER, 1/4
33 8866-2006 1 CONNECTOR, (includes item 34)
34 8859-1205 2 O-RING
35 9116-3110 1 HYDRAULIC TUBE
36 8471-8687 1 HOSE ASSY
37 8866-2140 1 RUN TEE, (includes item 34)
38 9116-3109 1 HYDRAULIC TUBE
39 9103-3138 1 TUBE CLAMP
40 7713-3498 1 CLAMP COVER
41 7713-3499 2 HEX HD CAPSCREW
42 Ref SOLENOID VALVE, (see page
10-11 for details)
43 8866-2152 1 BRANCH TEE, (includes item 20)
44 8471-8689 1 HOSE ASSY
45 Ref BRAKE VALVE ASSY, (see page
10-10 for details)
46 8866-2059 1 ELBOW, 90 DEGREES, (includes
item 26)
47 9108-3310 1 ELBOW, 90 DEGREES, (includes
item 26)
48 Ref ACCELERATOR PEDAL ASSY,
(see page 7-3 for details)
49 8471-8688 1 HOSE ASSY
50 9114-6059 1 BRAKE PEDAL
51 9108-3136 4 BUSHING
52 9116-3093 1 FOOT SWITCH
53 8820-1005 3 HEX HD CAPSCREW, 1/4-20X1,
GR5
54 8856-1107 3 FLAT WASHER, 1/4
Item Part No. Qty. Description Of Part
9116-5103 1 FLOOR PLATE ASSY, (includes all
items except 52 thru 54)
1 9116-6041 1 FLOOR PLATE WELDMENT
2 9020-6198 16" TRIM-LOK
3 9108-3312 1 CAM ROLLER
4 8855-1010 4 LOCKWASHER, 5/16
5 8850-1405 1 HEX JAM NUT, 5/16-24
6 9104-3214 1 SPRING
7 9108-1445 1 PUSH ROD
8 8850-1408 1 HEX JAM NUT, 1/2-20
9 9020-0284 1 SHAFT
10 8844-1001 2 SQUARE HD SET SCREW, CUP
POINT, 1/4-20X1/2"
11 8850-1406 2 HEX JAM NUT, 3/8-24
12 8882-1004 2 YOKE END
13 9002-7987 2 CLEVIS PIN
14 9108-1332 1 LINKAGE ROD
15 8820-1022 3 HEX HD CAPSCREW, 5/16-18X1-1/2,
GR5
16 8850-1005 3 HEX NUT, 5/16-18
17 Ref INCHING VALVE, (see page 10-13
for details)
18 8821-2228 2 SOCKET HD CAPSCREW, 5/16-18X
1-1/4, GR8
19 8866-2064 4 ELBOW, 90 DEGREES, (includes
item 20)
20 8859-1204 5 O-RING
21 8866-2105 1 ELBOW, 90 DEGREES, (swivel nut)
22 8363-3002 1 STRAIGHT THREAD CONNECTOR
23 9020-7856 1 COPPER GASKET
24 8471-8690 1 HOSE ASSY
25 8866-2019 1 CONNECTOR, (includes item 26)
26 8859-1206 3 O-RING
27 8866-2120 1 ELBOW, 45 DEGREES, (swivel nut)
* Revised illustration, description on items 5, 8, 10, 11 & 18, quantity on items 19 & 32
and revised item 49; removed item 55.
*
*
*
*
*
*
*
*
