MPC3868-KG
Item Part No. Qty. Description Of Part
9116-5013 1 HYDRAULIC RESERVOIR ASSY
(includes all items)
1 9114-3133 1 HYDRAULIC OIL TANK
(includes item 21)
2 9108-3070 1 FLUID LEVEL GAUGE
(includes items 3 & 4)
3 2 SCREW
4 2 WASHER
5 9114-3172 2 MINI CHECK COUPLING
6 8859-1210 3 O-RING
7 8866-1084 1 BULKHEAD UNION, 9/16-18X3/8
TUBE
8 8866-2105 1 ELBOW, 90 DEGREES (swivel nut)
9 9002-7179 1 BULKHEAD UNION, 90 DEGREES
10 9116-3141 1 TUBE ASSY
11 9114-3218 1 RETURN FILTER (includes one of
item 13 and item 14)
12 9108-3518 1 SUCTION FILTER (includes one of
item 13)
13 9114-3144 2 FILTER ELEMENT
14 9108-4022 1 COLOR CODED GAUGE
15 8866-2070 1 ELBOW, 90 DEGREES (includes
item 6)
16 8067-3009 1 ADAPTER, 90 DEGREES
17 8820-1036 4 HEX HD CAPSCREW, 3/8-16X1-1/4,
GR5
18 8856-1004 8 WASHER, 3/8
19 8832-1039 6 SELF TAPPING SCREW,
#10-32X1/2"
20 8820-1020 4 HEX HD CAPSCREW, 5/16-18X1,
GR5
21 1 PLUG
22 8856-1003 4 WASHER, 5/16
23 9116-1210 1 FILTER SUPPORT
24 9108-3069 1 FILLER BREATHER
25 8855-1011 4 LOCKWASHER, 3/8
26 8850-1006 4 HEX NUT, 3/8-16
27 8866-1013 1 MALE CONNECTOR
28 9108-3301 1 TANK FILTER
29 9108-3200 1 STRAIGHT CONNECTOR
30 8866-2106 1 ELBOW, 90 DEGREES, (swivel nut)
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
HYDRAULIC COMPONENTS
(9116-5013) Hydraulic Reservoir & Filters
Starting Serial No. 0255001
Original Issue 7-96
Revised 10-19-99
10-15 * Added item 30.
