BOOM
Retraction Chains
Starting Serial No. 0255001
Original Issue 11-96
Revised 5-7-97
KG 3-7
Item Part No. Qty. Description Of Part
1 8850-1412 1 HEX JAM NUT, 3/4-16 (torque to
100 ft.lbs.)
2 8850-1312 3 HEX NUT, 3/4-16 (torque to 100 ft.lbs.)
3 9002-7473 2 HARDENED WASHER, 3/4
4 Ref FOURTH BOOM SECTION (see
page 3-4 for details)
5 9116-3173 1 CHAIN CLEVIS
6 9116-3037 1 CHAIN, 3/4"
7 9116-3124 2 CHAIN PIN
8 8863-1302 8 COTTER PIN
9 9116-6027 1 ANCHOR BRACKET
10 8850-1414 1 HEX JAM NUT, 7/8-14 (torque to
100 ft.lbs.)
11 8850-1314 3 HEX NUT, 7/8-14 (torque to 100 ft.lbs.)
12 Ref THIRD BOOM SECTION (see page
3-3 for details)
13 9116-3171 1 CHAIN CLEVIS
14 9116-3036 1 CHAIN, 1"
15 9116-3123 2 CHAIN PIN
16 9108-1313 2 PIN KEEPER
17 8855-1013 4 LOCKWASHER, 1/2
18 8820-1065 4 HEX HD CAPSCREW, 1/2-13X1, GR5
19 8867-1001 2 GREASE FITTING
20 9116-1267 2 CHAIN SHEAVE PIN
21 9116-6026 1 ROLLER BRACKET
22 9116-5022 2 CHAIN ROLLER (includes items 23
& 24)
23 9116-3204 2 BUSHING
24 8692-1268 4 SEAL
25 9104-1451 4 THRUSTWASHER
9104-1450 AR THRUSTWASHER
9104-1449 AR THRUSTWASHER
9104-1596 AR THRUSTWASHER
26 Ref SECOND BOOM SECTION (see
page 3-2 for details)
27 9116-6022 1 ROLLER BRACKET
28 9116-3172 1 CHAIN CLEVIS
29 9116-1214 1 STOP BAR
30 8320-1061 8 HEX HD CAPSCREW, 3/4-10X1-3/4,
GR5 (torque to 340-365 ft.lbs.)
31 9002-7473 8 HARDENED WASHER, 3/4
32 9116-1212 1 CABLE ADJUSTMENT BLOCK
33 9116-3162 1 SPRING
34 Ref FIRST BOOM SECTION (see page
3-1 for details)
35 9116-3170 1 CHAIN CLEVIS
36 9116-1213 1 STOP BAR
37 9116-1211 1 CABLE ADJUSTMENT BLOCK
38 9116-3161 1 SPRING
SERVICE NOTES:
1). A chain wear gage, part number 9116-4084, is now available to check if your
boom chain has been stretched beyond spec.
* Added service note.
