Hydraulic circuits dump circuit – Gradall 544C-10 User Manual
Page 85
9-2
Item
Part No.
Qty.
Description Of Part
1
Ref
HYDRAULIC RESERVOIR ASSY
(see page 10-15 for details)
2
8471-8979
1
HOSE ASSY
3
8471-8748
1
HOSE ASSY
4
8471-8968
1
HOSE ASSY
5
8866-2070
1
ELBOW, 90 DEGREES (includes
item 44)
6
9114-3273
1
DUMP TUBE
7
9116-3140
1
TUBE ASSY
8
7713-3053
1
CLAMP SET
9
7713-3052
1
COVER PLATE
10
8820-1010
2
HEX HD CAPSCREW, 1/4-20X2 1/4,
GR5
11
8850-1004
2
HEX NUT, 1/4-20
12
8855-1009
2
LOCKWASHER, 1/4
13
8856-1107
2
FLAT WASHER, 1/4
14
8471-8999
1
HOSE ASSY
15
9105-3450
1
REDUCER ELBOW (includes item 37)
16
Ref
FRONT DRIVE MOTOR (see page
10-16 for details)
17
7713-3076
1
CLAMP
18
7713-3075
1
COVER PLATE
19
8820-1011
2
HEX HD CAPSCREW, 1/4-20X2 1/2,
GR5
20
8471-8947
1
HOSE ASSY
21
8866-1364
1
CAP
22
8471-8635
1
HOSE ASSY
23
8471-8745
1
HOSE ASSY
24
8471-8956
1
HOSE ASSY
25
8471-8746
1
HOSE ASSY
26
8471-8743
1
HOSE ASSY
PCN 960926-KG
HYDRAULIC CIRCUITS
Dump Circuit
Starting Serial No. 0255001
Original Issue 10-96
Revised 1-29-97
Item
Part No.
Qty.
Description Of Part
27
Ref
SOLENOID VALVE (see page 10-11
for details)
28
8859-1204
2
O-RING
29
8866-2064
1
ELBOW, 90 DEGREES (includes
item 28)
30
Ref
STABILIZER VALVE ASSY (see
page 10-23 for details)
31
8859-1206
1
O-RING
32
8866-2019
1
CONNECTOR (includes item 31)
33
8866-2120
1
ELBOW, 45 DEGREES (swivel nut)
34
8471-8287
1
HOSE ASSY
35
8866-2242
1
SWIVEL NUT RUN TEE, 3/4 TUBE
36
8866-2008
1
CONNECTOR (includes item 37)
37
8859-1207
2
O-RING
38
8365-1133
1
REDUCER W/ADAPTER
39
8866-2239
1
SWIVEL NUT RUN TEE, 3/8 TUBE
40
Ref
TRACTION LOCK VALVE (see page
10-21 for details)
41
Ref
HYDROSTATIC TRANSMISSION
(see page 10-18 for details)
42
Ref
FLOW DIVIDER ASSY (see page
10-9 for details)
43
Ref
MAIN CONTROL VALVE (see
page 10-14 for details)
44
8859-1210
3
O-RING
45
8866-2028
2
CONNECTOR (includes item 44)
46
Ref
THERMAL BYPASS VALVE ASSY
(see page 10-12 for details)
47
8471-8945
1
HOSE ASSY
48
Ref
OIL COOLER ASSY (see page 5-4
for details)
49
8866-2005
1
CONNECTOR (includes item 28)
*
* Changed part number on item 4.
