Gradall 544C-10 User Manual
Page 143
Item
Part No.
Qty.
Description Of Part
9116-5010
Ref
AUXILIARY HYDRAULICS
W/ELECTRIC, (includes all items)
1
9116-3174
1
HOSE CARRIER
2
8826-1030
8
SOCKET BUTTON HD CAPSCREW,
3/8-16X1-1/4
3
8852-1306
8
HEX LOCKNUT, 3/8-16
4
8856-1004
12
FLAT WASHER, 3/8
5
9002-7187
7
TY-RAP
6
8471-8959
2
HOSE ASSY
7
9114-3141
3
CORD CONNECTOR
8
9136-3068
1
TUBE ASSY
9
9108-3217
6
CUSHION CLAMP, 5/8
10
9020-7463
5
CUSHION CLAMP, 3/4
11
8866-1085
4
BULKHEAD UNION, 3/4-16X1/2 TUBE
12
9116-3060
1
TUBE ASSY
13
9116-3059
1
TUBE ASSY
14
9116-3062
1
TUBE ASSY
15
9116-3061
1
TUBE ASSY
16
9116-3100
2
STRAIGHT THREAD BULKHEAD
FITTING
17
7713-3389
3
STACK BOLT
18
7713-3136
3
TUBE CLAMP
19
7713-3137
3
COVER PLATE
20
8820-1023
3
HEX HD CAPSCREW, 5/16-18X1-3/4,
GR5
21
9116-3066
1
TUBE ASSY
22
9116-6038
1
HOSE GUIDE BRACKET
23
8820-1032
3
HEX HD CAPSCREW, 3/8-16X5/8,
GR5
24
8855-1011
9
LOCKWASHER, 3/8
25
8856-1109
7
FLAT WASHER, 3/8
26
9116-1138
1
HOSE SHEAVE PIN
27
9114-3024
1
HOSE SHEAVE
28
9104-1451
2
THRUSTWASHER
29
1440-4793
AR
UNION 76 MEGAPLEX GREASE
30
9104-1449
AR
THRUSTWASHER
31
9104-1450
AR
THRUSTWASHER
32
9104-1596
AR
THRUSTWASHER
33
8820-1074
1
HEX HD CAPSCREW, 1/2-13X3-1/4,
GR5
34
8855-1013
1
LOCKWASHER, 1/2
35
9136-3151
1
AUX. BOOM WIRING HARNESS
36
9020-7464
8
CUSHION CLAMP, 1/2
37
9104-3120
4
CUSHION CLAMP
38
8471-9455
3
HOSE ASSY
39
8471-9018
2
HOSE ASSY
40
8820-1017
2
HEX HD CAPSCREW, 5/16-18X5/8,
GR5
41
8855-1010
4
LOCKWASHER, 5/16
42
8850-1008
3
HEX NUT, 1/2-13
43
8850-1108
3
HEAVY HEX JAM NUT, 1/2-13
44
9112-3054
3
COMPRESSION SPRING
45
9002-7180
2
90 DEGREE BULKHEAD FITTING
46
9112-1134
3
SPRING RETAINER
47
9112-6032
1
CABLE TAKE-UP SUPPORT
48
9136-6015
1
HOSE TAKE-UP WELDMENT
49
9116-6068
2
HOSE TAKE-UP WELDMENT
50
8471-8637
1
HOSE ASSY
51
9120-3039
1
CLAMP SUPPORT
52
8855-1009
2
LOCKWASHER, 1/4
53
8856-1107
2
FLAT WASHER, 1/4
OPTIONAL EQUIPMENT
(9116-5010) Auxiliary Hydraulics W/Electric
Starting Serial No. 0255001
Original Issue 9-96
Revised 10-5-01
Item
Part No.
Qty.
Description Of Part
54
8850-1004
2
HEX NUT, 1/4-20
55
9020-4244
1
MALE HYDRAULIC COUPLER
56
9104-3126
1
DUST CAP
57
9104-3321
2
STRAIGHT THREAD BULKHEAD
FITTING
58
8871-2304
2
REDUCING BUSHING, 1/2X3/8
59
9020-4245
1
FEMALE HYDRAULIC COUPLER
60
9104-3125
1
DUST PLUG
61
9112-1139
1
RECEPTACLE BRACKET
62
9020-7661
1
SIX CONTACT RECEPTACLE
63
8820-1005
2
HEX HD CAPSCREW, 1/4-20X1, GR5
64
8852-1304
2
HEX LOCKNUT, 1/4-20
65
8820-1018
2
HEX HD CAPSCREW, 5/16-18X3/4,
GR5
66
8850-1005
1
HEX NUT, 5/16-18
67
9112-6023
1
CABLE BRACKET WELDMENT
68
8820-1036
4
HEX HD CAPSCREW, 3/18-16X1-1/4,
GR5
69
8850-1006
4
HEX NUT, 3/8-16
70
8882-1002
1
YOKE END
71
8863-3001
1
YOKE PIN, 1/4
72
8863-1302
1
COTTER PIN, 1/16X3/4
73
8850-1404
1
HEX JAM NUT, 1/4-28
74
9116-3131
1
PUSH-PULL CABLE
75
9112-3062
1
CABLE ADAPTER BONNET
76
8471-8685
1
HOSE ASSY
77
9116-3097
1
TUBE ASSY
78
9116-3096
1
TUBE ASSY
79
12"
LOOM, 5/16 I.D.
80
9112-3051
1
MOLDED RUBBER BUSHING
81
1440-2248
AR
3M ADHESIVE
82
9112-6025
1
LEVER BRACKET
83
9112-6024
1
LEVER WELDMENT
84
Ref
5 BUTTON HANDLE, (see page 13-21
for details)
85
8850-1112
1
HEAVY HEX JAM NUT, 3/4-10
86
9112-6027
1
PIN WELDMENT
87
9108-3136
2
BUSHING
88
7736-3232
1
RECEPTACLE CONNECTOR
89
7736-3228
6
PIN CONTACT
90
9114-3107
1
STRAIN RELIEF
91
9114-3105
1
AUX. WIRING HARNESS
92
9112-3022
1
ELBOW, 90 DEGREES - LONG
93
8866-2020
2
CONNECTOR, (includes item 94)
94
8859-1207
2
O-RING
95
8866-2106
1
ELBOW, 90 DEGREES, (swivel nut)
96
8471-8686
1
HOSE ASSY
97
9103-3394
1
AUX. CONTROL DECAL
98
9002-8662
2
WAVE BEND WASHER
99
8698-3193
1
MALE BULLET
100
9103-3391
1
INSULATED RING TERMINAL
101
9002-8968
1
CONNECTOR
102
8471-8943
1
HOSE ASSY
103
9136-3185
1
AUX BOOM WIRING HARNESS
104
9136-1032
1
DISCONNECT PLATE
105
8866-1014
1
MALE CONNECTOR, 3/4X1/2 TUBE
106
8820-1035
2
HEX HD CAPSCREW, 3/8-16X1, GR5
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
13-4
PCN 000525-MBC
*
*
*
*
* Revised illustration, part number on items 2, 7, 8, 35, 37, 48 & 51 thru 54, quantity
on items 5, 24 & 38 and description on items 11, 58, 69, 71, 72 & 85; added items 103 thru 106.
