HYDRAULIC COMPONENTS
(9116-5031) Stabilizer Valve Assembly
Original Issue 11-96
10-23 KG
Item Part No. Qty. Description Of Part
9116-5031 1 STABILIZER VALVE ASSY (includes
all items)
9116-3164 1 STABILIZER VALVE (includes
items 1 thru 7)
1 1 VALVE BODY (not sold separately,
order P/N 9116-3164)
2 9116-4053 1 CHECK VALVE
9116-4054 1 CHECK VALVE SEAL KIT
3 9116-4055 2 SOLENOID VALVE ASSY (includes
item 4)
9116-4056 2 SOLENOID VALVE SEAL KIT
4 9114-4158 2 COIL
5 9116-4057 1 PORT PLUG
9116-4058 1 PORT PLUG SEAL
6 9116-4059 2 PORT PLUG
9116-4060 2 PORT PLUG SEAL
7 9116-4063 1 ORIFICE PLUG
8 8859-1206 1 O-RING
9 8866-2019 1 CONNECTOR (includes item 7)
10 8866-2120 1 ELBOW, 45 DEGREES (swivel nut)
11 8859-1205 2 O-RING
12 8866-2065 2 ELBOW, 90 DEGREES (includes
item 11)
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
