54
6.
Operation:
Mode
Flow
Chart
Operation Screen Reference
6.
Manually move the slider and
match to the desired position.
Press the Return key.
The controller status will be
displayed on the bottom row
of the screen.
Servo Control: OFF
Position: 100.00
You can change the position
No.you want to input with the
and key.
7.
Press the key to select
“Yes.”
8.
Press the Return key. As for Vel, Acc, Dcc, etc., the
initial value set with the user
parameter will automatically
be input.
(Note) If scan is performed
without executing homing,
the error message “Homing
Incomplete” will be displayed.
Return to the screen of 6
above with the ESC key to
put into the servo ON status
key
9.
Press the key.
10.
to execute homing.
and press the
