17
4.
Functions
and
Specications
of
T
eaching
Pendant
(7) PARAMETER mode select key
Moves to the “User Parameter” mode. This key is valid when the LED of the PARAMETER mode
select key is lit.
(8) ADJUST mode select key
Moves to the “User Adjustment” mode. This key is valid when the LED of the ADJUST mode
select key is lit.
(9) TP operation mode select keys
6HOHFW7($&+7HDFKPRGH7($&+7HDFKPRGH021,70RQLWRUPRGHRU
MONIT2 (Monitor 2 mode).
The mode will move to the TP operation mode selected.
After movement, the LED of the operation mode selected lit.
(10) ESC key
- Return to the parent screen display
Although Teaching Pendant operation is composed of several layer nests, using this key will
return the user to one upper layer (parent screen).
When you don’t understand the operation, retry operation after returning to the upper layer with
the ESC key.
- Input data cancel during data input operation
If you press this key during data input operation, the input data will be canceled.
- Stop switch during movement or continuous movement
Once this switch is pushed down during movement or continuous movement, operation will
decelerate and stop immediately.
(11) PAGE UP/PAGE DOWN key
Changes screens by incrementing or decrementing edit and display item No. (Position No., Error
List No., User Parameter No.).
(12) ERROR RESET key
When an error occurs at any level that allows recovery without software reset, the error reset and
message clear can be performed with this key.
(13) WRT key
Transfers edited data to the controller. (Data will be saved to the memory of the controller.)
Only the data displayed on the LCD will be transferred. (Multiple position No. can’t be transferred
all together at the same time.)
If it is position data, transferred all together at position data.
