46
Chapter 2
Configuration
FRU Configurations
Monitor-Type Selection
The B1000/C3000 supports the following monitors:
• 19-inch, 1280
×
1024 color monitor, 75 Hz (A4575A)
• 19-inch, 1600
×
1200 color monitor, 75 Hz (A4575A)
• 21-inch, 1280
×
1024 color monitor (stereo capability), 75 Hz (A4576A)
• 21-inch, 1600
×
1200 color monitor, 75 Hz (A4576A)
The
monitor type
does not have to change since the workstation is set up to support the
above mentioned monitors. However, if for some reason the
monitor
type
needs to
change, refer to Chapter 6, Boot Console Handler, of this manual.
Note that connection to earlier HP monitors with 15-pin mini-DSub cables can be made
using the A4168A adapter cable shipped with your system miscellaneous kit.
NOTE
Unsupported monitors may “lock up” if unable to sync to a scan rate provided
by the workstation.
NOTE
The B1000/C3000 workstations support a maximum of four V
ISUALIZE
-EG
graphics cards with four monitors. One, two, three, or four V
ISUALIZE
-EG
graphics cards may be installed per workstation.
