Figure444. removing the floppy disk drive, Figure 4-44.. removing the floppy disk drive – HP B1000 User Manual
Page 131
Chapter 4
131
Field Replaceable Units
FRU Removal and Replacement
Figure 4-44. Removing the Floppy Disk Drive
5. Place the floppy disk blank in the floppy disk bracket and insert the four floppy disk
mounting screws into the bracket and tighten them. See Figure 4-45.
Floppy Disk
Mounting Screw
(four, T-10)
Floppy Disk Drive
Floppy Disk Bracket
Bracket
Screw
