Chapter 4 139
Field Replaceable Units
FRU Removal and Replacement
3. Remove the four T-15 Torx screws from the hard disk drive bracket. See Figure 4-53..
Figure 4-53. Removing the Hard Disk Drive from the Bracket
4. Slide the assembly into its hard drive slot, and push inward on the release lever until
the front of the hard dive bracket is flush with the system unit. See Figure 4-54.
Mounting Grommet
(do not remove)
T-15 Torx Shoulder
Screw
Hard Disk Drive
Bracket
Plastic Release Hook
Plastic Release
Hard Disk
Drive
Lever
