22 Chapter 1
Product Information
System Unit Front Panel Controls
Figure 1-2. LCD Symbols
System Power Switch
Use the Power switch to power the system unit on and off. When you use the soft power
down procedure, the B1000/C3000 workstations’ hardware is designed to produce the
proper diagnostic and self test messages, and broadcasts a warning message to remote
terminals that it is about to shutdown. The operating system executes an automatic
shutdown -q command. Turning the power switch back on again automatically boots up
the HP-UX 10.20 or later operating system if the system has been configured to auto
boot . For information on setting auto boot , refer to the section “Setting the Auto Boot
and Auto Search Flags” on page 178.
Storage Device Controls and Features
This workstation allows either or both of the following internal storage devices: CD drive
or floppy disk drive. The following sections describe the controls and features of these
devices.
NOTE You cannot have two internal storage devices of the same type. For example,
you cannot have two floppy disk drives, and you cannot have two CDROMs.
Figure 1-3. shows the operating controls and features of the CD drive, and Table 1-1.
describes those controls and features.
