Figure451. the hard drive slots, Figure452. removing the hard disk drive – HP B1000 User Manual
Page 138
138
Chapter 4
Field Replaceable Units
FRU Removal and Replacement
Figure 4-51. The Hard Drive Slots
2. Open the hard drive slot by pressing the plastic release hook upward and pulling
outward on the release lever as shown in Figure 4-52.. As you pull outward on the
release lever, the hard drive bracket will slide out of its slot.
Figure 4-52. Removing the Hard Disk Drive
SCSI ID 5
SCSI ID 6
Hard Disk Drive
Slots
Hard Disk Drive
Bracket
Plastic
Release Hook
Release Lever
Hard Disk Drive
