Figure 4-24 – HP B1000 User Manual
Page 119
Chapter 4
119
Field Replaceable Units
FRU Removal and Replacement
Figure 4-24. Removing the CD Drive Bracket and Blank
5. Read the CAUTION statement at the beginning of this section. Next remove the CD
Drive from its shipping container, and using the four T-10 screws mount the disk drive
to the bracket as shown in Figure 4-24.
Bracket
CD Drive Bracket
Blank
Blank Filler Screws
(T-10 Torx Screws)
Bracket Screws
