HP B1000 User Manual
Page 127
Chapter 4
127
Field Replaceable Units
FRU Removal and Replacement
Figure 4-37. Removing the Floppy Disk Bracket and Blank
5. Read the CAUTION statement at the beginning of this section. Next remove the floppy
disk drive from its shipping container, and using the four T-10 blank screws mount the
disk drive to the bracket as shown in Figure 4-38.
Blank
Bracket
Screw
Bracket
Blank Filler Screws
Bracket Screw
