Chapter 4
101
Field Replaceable Units
FRU Removal and Replacement
Closing the Left Side Panel of the System Unit
Perform these steps to close the left side panel.
NOTE
Power supply thumbscrews must be fully tightened before closing the left side
panel. Failure to tighten thumbscrews may damage the left side panel.
1. Hold the left side panel so that the hook hinges can be inserted into their hinge slots.
See Figure 4-6. Note that the hinge slots are located on the far right edge of the system
unit (using the back of the system unit as the reference).
2. Swing the back edge of the panel toward the system unit’s back edge and press the
outside edges of the side panel tightly against the system unit. This will ensure a tight
seal of the EMI gaskets.
3. Secure the side panel in place by screwing the top and bottom slotted T-15 Torx thumb
screws into their brackets. The recommended torque setting is 6 inch-pounds.
