Chapter 2 Troubleshooting Windows NT boot problems
38 Profile XP Service Manual 23 July 2004
Re-installing and configuring drivers
In the event that the display, Ethernet, or RS-422 drivers are corrupted or the settings
lost, here is the information you need for re-installing the drivers and making settings
that return the Profile XP media platform to its factory default conditions. Drivers for
the Ethernet adapter, the VGA adapter, and the RS-422 board are located in
c:\profile\Drivers. When a dialog box requests a location for a file normally found on
the CD-ROM, start the path name with c:\profile\Drivers\…
In the table below, note that there are two sets of display drivers and ethernet adapters,
each set associated with a system processor board rear panel. Select the drivers
associated with the rear panel that matches the system processor in your media
platform. Note also that the one RS-422 driver is used with either system processor
board.
Hardware Driver Location Factory settings
VGA adapter for
use with this
system processor. ATI Rage PRO c:\profile\Drivers\ATI_RAGE Desktop Area: 1024 X 768
Refresh Rate: 70 Hz
Color Palate: 24 bit,
16,777,216 Colors
Ethernet adapter
for use with this
system processor. Intel EtherExpress
PRO Adapter 82558 c:\profile\Drivers\Intel_PRO Memory Address:
0xFC000000
I/O Address: 0x1000
Interrupt: 9
RS-422 board for
use with all
system
processors. Comtrol RocketPort c:\profile\Drivers\rocket Com Port Range:
Starting COM Port: COM3
Scan Rate (ms): 1
VGA adapter for
use with this
system processor. Intel 810 Graphics
Controller Hub c:\profile\Drivers\Intel_810 Desktop Area: 1024 X 768
Refresh Rate: 70 Hz
Color Palate: 24 bit,
16,777,216 Colors
Ethernet adapter
for use with this
system processor. Intel (R) GD82559ER
Fast Ethernet Adapter c:\profile\Drivers\Intel_GD82559ER Speed and Duplex set to
Auto Select.
