Preface
22 Profile XP Service Manual 23 July 2004
PVS3500 features
• Up to 7 channels of broadcast-quality video.
• HD decoders can play MPEG-2 4:2:0 SD and HD clips through either an SD or an
HD SDI output, down- or up-converted as required.
• MPEG-2 4:2:0 @ Main Level from 24-80Mbs, long GOP (for HD)
• MPEG-2 4:2:2 @ Main Level from 4 to 25Mb/s or 50Mb/s (requires 50Mb/s
option)
• SMPTE 292M, 1.485 Gbs Serial Digital I/O (includes downconverted SD SDI and
composite analog monitor with text overlay and timecode burn-in)
• SMPTE 259M, 270MHz Serial Digital I/O (Optional analog monitor with
timecode burn-in and text overlay)
• 1080i and 720p line rates for HD, 50 and 59.94, accepts house black and tri-level
sync reference
• DVCPRO 25 video compression
• DVCPRO 50 video compression (requires 50Mb/s option)
• MPEG-D10: I-frame at 30, 40, or 50Mb/s CBG (requires 50Mb/s option)
• 525/60 or 625/50 operation: accepts NTSC, PAL
PVS 3500 Series channel configurations by model
Model
Number Number of HD
MPEG Encoder
Boards Number of HD
MPEG Decoder
Boards Number of SD
Video Processor
Boards Channel
Configuration
PVS3502 0 1 0 2 HD/SD out
PVS3504 0 2 0 4 HD/SD out
PVS3512 1 1 0 1 HD in
2 HD/SD out
PVS3514 1 2 0 1 HD in
4HD/SD out
PVS3522 0 1 1 2 SD in
2 HD/SD out
PVS3524 0 2 1 2 SD in
4 HD/SD out
PVS3532 1 1 1 2 SD in
1 HD in
2 HD/SD out
PVS3534 1 2 1 2 SD in
1 HD in
4 HD/SD out
