Chapter 11 Parts removal and replacement
120 Profile XP Service Manual 23 July 2004
Cable Assy., Standby/Power Switch 174-4042-XX
Cable, RS422 to I/O Panel 174-4343-XX
Cable, Real Time System board to I/O Panel 174-4344-XX
Top Cover 200-4523-XX
Front Bezel 333-4327-XX
Air Filter, Door 378-0474-XX
Air Filter, Bezel 378-0475-XX
Front Panel Assy. 426-2602-XX
Fan Assy. (Fan tray, three fans, power distribution board) 386-7139-XX
Mouse 119-4330-XX
Keyboard 119-5662-XX
Cable Assy., Fibre Channel Network
Cable Assy., Fibre Channel, FC Disk to RAID
Cable Assy., Ethernet
Cable Assy., Audio board to Audio interface (PAC/XLR/BNC 216)
a.
When replacing the system processor board, check the part number on the
board and request a replacement board with that number.
b.
PVS2000 Series requires the -02 or later version of the Real Time System
board.
Description Part Number
