Preface
20 Profile XP Service Manual 23 July 2004
PVS2000 features
• Up to 4 high definition (HD) channels of broadcast-quality video
• MPEG-2 4:2:0 @ Main Level from 24-80Mbs, long GOP (for HD)
• SMPTE 292M, 1.485 Gbs Serial Digital I/O (includes downconverted SD SDI and
composite analog monitor with text overlay and timecode burn-in)
• 1080i and 720p line rates for HD, 50 and 59.94, accepts house black and tri-level
sync reference
PVS 2000 Series channel configurations by model
Model
Number Number of MPEG
Encoder Boards
a
a.
MPEG Encoder and Decoder boards in PVS2000 series are High Definition.
Number of MPEG
Decoder Boards Channel
Configuration
PVS2012 1 1 1 in/2 out
PVS2013 1 2 1 in/ 3 out
PVS2004 0 2 0 in/4 out
PVS2022 2 2 2 in/2 out
PVS2212 1 HD, 1 SD 1 HD, 1 SD 2 in/2 out (SD)
1 in/2 out (HD)
