Profile XP Media Platform features
23 July 2004 Profile XP Service Manual 19
PVS1100 features
• Up to 8 standard definition (SD) channels of broadcast-quality video
• DVCPRO 25 video compression
• DVCPRO 50 video compression (requires 50Mb/s option)
• MPEG-2 4:2:2 @ Main Level from 4 to 25Mb/s or 50Mb/s (requires 50Mb/s
option)
• MPEG-D10: I-frame to 50Mb/s CBG (requires 50Mb/s option)
• SDTI (optional): two channels, each can be configured as input or output.
DVCPRO 25 input at 1x, 2x, 4x; output at 1x, 4x. DVCPRO 50 input at 1x, 2x;
output at 1x.
• SMPTE 259M, 270MHz Serial Digital I/O (Optional analog monitor with
timecode burn-in and text overlay)
• 525/60 or 625/50 operation: accepts NTSC, PAL
PVS 1100 Series channel configurations by model
Model
Number Number of video
codecs Channel
Configuration
PVS1102 2 2 play/record
PVS1104 4 4 play/record
PVS1106 6 6 play/record
PVS1148 8 4 play/record
plus 4 play
PVS1108 8 8 play/record
