Profile XP Media Platform features
23 July 2004 Profile XP Service Manual 21
PVS3000 features
• Up to 7 channels of broadcast-quality video
• Standard and high definition channels can record and play concurrently
• MPEG-2 4:2:0 @ Main Level from 24-80Mbs, long GOP (for HD)
• MPEG-2 4:2:2 @ Main Level from 4 to 25Mb/s or 50Mb/s (requires 50Mb/s
option)
• SMPTE 292M, 1.485 Gbs Serial Digital I/O (includes downconverted SD SDI and
composite analog monitor with text overlay and timecode burn-in)
• SMPTE 259M, 270MHz Serial Digital I/O (Optional analog monitor with
timecode burn-in and text overlay)
• 1080i and 720p line rates for HD, 50 and 59.94, accepts house black and tri-level
sync reference
• DVCPRO 25 video compression
• DVCPRO 50 video compression (requires 50Mb/s option)
• MPEG-D10: I-frame at 30, 40, or 50Mb/s CBG (requires 50Mb/s option)
• 525/60 or 625/50 operation: accepts NTSC, PAL
•
PVS 3000 Series channel configurations by model
Model
Number Number of HD
MPEG Encoder
Boards Number of HD
MPEG Decoder
Boards Number of SD
Video Processor
Boards Channel
Configuration
PVS3004 0 1 1 2 SD out
2 HD out
PVS3014 1 1 1 2 SD out
1 HD in
2 HD out
PVS3024 0 1 1 (4 Ch.) 2 SD in
2 SD out
2 HD out
PVS3034 1 1 1 (4 Ch.) 2 SD in
2 SD out
1 HD in
2 HD out
