5 and 2 m/e control panel – Grass Valley Kayak HD Installation v.6.8.8 User Manual
Page 25
Kayak HD — Installation and Service Manual
25
System Components
1.5 and 2 M/E Control Panel
Figure 3. Kayak HD 150C, 200C, and 200 Control Panel
Figure 4. 2 M/E Control Panel, Rear View
USB
P/S 2
3
4
8448_05_
r0
(Future use)
(Future use)
PS/2 Port
48V DC Power In
(from Frame)
Redundant
DC Power In
USB #4
LAN
RS 485
RS 232
USB #2
