170 Kayak HD — Installation and Service Manual
Appendix A — Specifications
Table 19. Kayak HD Video Standards
Table 18. Analog Reference Input
Video Standard
For HD Video: Tri-level Sync, Analog equivalent to the standard being
used
For SD Video: Color Black, Analog equivalent to the standard being
used
Return loss > 40dB, up to 5 MHz
Connectors 2 each BNC loop through for both HD and SD inputs
Impedance 75 ohm external
HD Mode SD Mode
1080i 29.97/30 SMPTE 274M Table 1-4, 5 525i 59.94 SMPTE 259M
1080i 25 SMPTE 274M Table 1-6 625i 50 SMPTE 259M
1080sF 24/23.976 SMPTE 211 Table 1-15, 16
720p 60/59.94/50 SMPTE 296 Table 1-1, 2
